FULL ELECTRIC STACKER (WALKY TYPE)

PRODUCT DESCRIPTION

A machine that moves quickly, ensuring manoeuvrability even in tight spaces, lifts to a great height, and above all, is economical and flexible enough to be operated by anyone.

The Electric Stacker offers it all - an efficient substitute to forklifts during these challenging times, well suited for all transportation requirements in your warehouses.

It moves more loads efficiently with a full-function control handle with thoughtfully placed switches allowing the operator to intuitively manage all functions.

Heavily reinforced fork tips and carbon steel chassis make it the ideal choice for rigorous use, even with heavy loads.

The AC control system with the rugged drive train allows fast acceleration and quick direction change while protecting the gearbox.

The fail-safe braking system, anti-pinning button etc ensure operator safety at every step of the operation.

FEATURES

  • Mast

    For the electric pallet stacker, we choose the highest specification forklift channel steel to make the mast which ensures the machine’s stability and carrying capacity.

    Specifically, use 12C forklift channel steel for the outer mast and #12J forklift channel steel for the inner mast.

    These two types of channel steel are formed by hot rolled which have high bending and torsional strength and good fatigue resistance.

    So, it is especially suitable for material handling equipment.

  • Fork

    The forks are made of thickened high-strength structural steel plate.

    Moreover, we reinforced the fork with a special design steel plate for both the outer side and the inner side of the fork to ensure the fork does not deform when loading heavy cargo.

  • Drive Wheel System

    The height-adjustable auxiliary wheels for the pedestrian pallet stacker which make the driving wheels have good contact with the ground and ensure no skidding.

  • Hydraulic Cylinder

    The hydraulic cylinder is made by high-precision automatic welding.

    The high-quality cylinder ensures the machine has strong power that carries heavy cargo.

    Moreover, we added a lowering buffer function.

    When the fork frame falls close to the end of the cylinder stroke, it will automatically slow down the descent speed until the end of the cylinder stroke.

    This function can reduce impact and noise when operating, increase the service life of the oil cylinder, and make the operation more comfortable.

  • Power System

    For the controller, we used a high-quality controller that ensures the stacker has stable performance and precise control.

    For the hydraulic station, we used a high-performance 24V/3KW hydraulic station that has the advantages of low noise and low vibration.

    For the battery, two sets of 12V / 85Ah large capacity maintenance-free batteries that meet the needs of long-term operation.

  • Braking System

    Two-position mechanical brake: tiller arm at vertical and horizontal position.

    Emergency brake: cut off all power and brake immediately, so the stacker is always safe.

    Anti-collision belly switch: The stacker stops quickly when the operator operates the belly switch and prevents squeezing injury in an emergency.

Model Unit HFES-2025W HFES-2030W HFES-2035W
Max. load capacity kg 2000 2000 2000
Max. lifting height mm 2500 3000 3500
Max. load at Max. lifting height kg 1600 1250 1000
Min. lifting height mm 90 90 90
Load center mm 600 600 600
Turning radius mm 1665 1665 1665
Mast Type 2 stage mast 2 stage mast 2 stage mast
Net Weight kg 1000 1050 1100
Overall Length L (mm) 2010 2010 2010
Overall Length,incl.pedal L1(mm) 2415 2415 2415
Overall Width W(mm) 820 820 820
Overall Height,mast lowered H (mm) 1765 2015 2165
Overall Height,mast extended H1(mm) 2950 3460 3760
Fork Dimensions(L3*W2*H5) mm 1150*175*60 1150*175*60 1150*175*60
Forks Outside Width mm 560/680 560/680 560/680
Forks inside Width mm 210/330 210/330 210/330
Wheel type PU PU PU
Wheels number drive/balance/load 1/1/4 1/1/4 1/1/4
Tyre size,drive mm Φ230*70 Φ230*70 Φ230*70
Tyre size,load mm Φ80x70 Φ80x70 Φ80x70
Tyre size,balance mm Φ115x50 Φ115x50 Φ115x50
Driving motor kw 1.5 1.5 1.5
Lifting motor kw 2.5 2.5 2.5
Steering systerm Electromagnetic Electromagnetic Electromagnetic
Battery V/Ah 24/210 24/210 24/210
Battery continues working time h 4 4 4
Max.Driving speed, load/unload km/h 3.5 / 5.5 3.5 / 5.5 3.5 / 5.5
Max.Lifting speed, load/unload mm/s 70/120 70/120 70/120
Max.Lowering speed, load/unload mm/s 110/90 110/90 110/90
Max.climbing ability, load/unload % 4 / 6 4 / 6 4 / 6
Service brake Electromagnetic Electromagnetic Electromagnetic
